The roll-formed PV mounting rail system is a high-strength, weight-optimized structural framework designed for securing photovoltaic modules in residential rooftop, commercial flat-roof, and utility-scale ground-mounted solar installations. Manufactured by advanced cold roll-forming technology from continuous galvanized steel or aluminum alloy coils, the system includes C/U/Z-shaped rails, purlins, module carriers, and connecting brackets with in-line punched holes and embossing.
| Item | Description |
| Profile Type | C-channel / U-rail / Z-purlin / custom open-section |
| Material Thickness | 1.2 – 3.0 mm (steel) / 1.5 – 2.5 mm (aluminum) |
| Standard Length | 2.1m / 4.2m / 5.8m or custom cut-to-length |
| Surface Finish | HDG (≥65µm) or Zn-Mg coat / Clear or black anodized |
| Design Life | 25 years (structural integrity warranty) |
| Certifications | ISO 9001, TÜV, CE (upon request) |
Material Options: High-strength galvanized steel (SGH340/Q235/Q355, Zn-Al-Mg coating ≥275g/m²) or AL6005-T5 aluminum alloy (anodized ≥10µm)
Manufacturing: Cold roll-formed with tight dimensional tolerances (±0.2mm), in-line servo punching for pre-drilled mounting holes/slots
Structural Performance: Engineered to withstand up to 60m/s wind load and 1.4kN/m² snow load per AS/NZS 1170, IEC 61215, and Eurocode standards
Corrosion Resistance: Hot-dip galvanized or Zn-Mg coated steel / anodized aluminum for 25-year outdoor service life
Installation: Lightweight, pre-slotted rails enable rapid module alignment with mid/end clamps—reducing on-site labor time by up to 30%
Versatility: Compatible with framed and frameless PV modules; suitable for pitched roof, flat roof, ground mount, carport, and solar tracker applications
